Leybold Phoenix Vario w/ EcoDry65+
This Leybold Phoenix Vario Leak Detector with EcoDry65plus (55 m3/hr) is fast, quiet and equipped with integrated WiFi on a purpose built 4 wheeled cart. Operator friendly color touch screen with intuitive menus and integrated data logging make this a versatile leak detector suitable for many applications.
Minimum detectable helium leak rate <5E-12
3 year factory warranty on filaments: dual iridium/yttria-oxide
Test port DN 25 ISO-KF
Please call for a complete quote.
The PHOENIX Vario has no built-in backing pump, and therefore has the smallest installation space with maximum flexibility.
The type and size of the backing pump can be chosen freely depending on applications and process requirements.
The PHOENIX Vario thus combines the excellent properties of the PHOENIX 4 series with the required pumping system. In that way both oil-sealed and dry backing pumps can be selected and the fore vacuum suction capacity can be adapted perfectly to the target application.
Advantages to the User
Application-optimized pumping speed
Extremely small installation space
Very light weight
Highly reliable measuring system
Simple, intuitive handling
Very high detection sensitivity
Convenient remote control via smartphone or tablet PC without software installation
Variety of interfaces for optimal device communication
Innovative color touch display
Extremely short response times
Internal data memory as well as simple data output via USB
